Silicone Washer Caps
silicone washer caps are designed to cover threaded studs and even plug plain and threaded holes. They mask off the stud/hole and leave a circular grounding or earthing area around it.
Description
silicone washer caps
Recommended for powder coating, e-coating, plating and anodizing
Withstands temperatures up to 230°C
Can be used to both cover studs or plug holes
Washer design eliminates the need for two-stage masking
Reusable
Product parameters
Material: Silicone
Standard Color: Various (color coded for sizing)
Optional Colors: Transucent, Black
OEM ODM: Welcome!
| Dimension | Applicable thread | Part No. | |||
| D | d | d1 | H | ||
| 12.7 | 3.2 | 6.6 | 25.4 | 01036013 | |
| 12.7 | 4 | 8.1 | 25.4 | 01036014 | |
| 12.7 | 4.4 | 9.8 | 25.4 | 01036015 | |
| 12 | 2.7 | 6 | 25.4 | M3 | 01036016 |
| 12 | 3.7 | 6.5 | 25.4 | M4 | 01036017 |
| 15 | 4.6 | 8 | 25.4 | M5 | 01036018 |
| 15 | 5.6 | 8.5 | 25.4 | M6 | 01036019 |
| 18 | 7.5 | 10.5 | 25.4 | M8 | 01036020 |
| 20.5 | 9.5 | 12.5 | 38.1 | M10 | 01036021 |
| 25 | 11.5 | 16.5 | 38.1 | M12 | 01036022 |
| 31 | 15.5 | 20.5 | 38.1 | M16 | 01036023 |
| 38 | 19.5 | 24.5 | 38.1 | M20 | 01036024 |
| 12.7 | 2.5 | 5.7 | 25.4 | 01036025 | |
| 12.7 | 3.6 | 8.2 | 25.4 | 01036026 | |
| 12.7 | 7.5 | 10.5 | 25.4 | 01036028 | |
| 15.2 | 4.6 | 8.0 | 25.4 | 01036029 | |
| 17.1 | 7.6 | 10.6 | 25.4 | 01036030 | |
| 17.8 | 11.7 | 14.5 | 25.4 | 01036031 | |
| 20.0 | 5.6 | 8.7 | 25.4 | 01036033 | |
| 25.4 | 7.5 | 10.5 | 25.4 | 01036034 | |
| 25.4 | 12.7 | 15.4 | 25.4 | 01036035 | |
*Tip: Please take advantage of our free samples to test parts in your specific application/environment before ordering.
